HKS Super Turbo Muffler Exhaust for Mitsubishi EVO 10 / EVO X 31029-AM004

Super Turbo Muffler

"High-dimensional Super Turbo Muffler Debut"

Exhaust Efficiency & Sound Pressure Reduction are implemented together.

The turbo engine master HKS challenged to implement the following 3 characteristics together to develop Super Turbo Muffler.

Effective on stock to high performance vehicles w/ upgraded turbines.

The performance exhaust sound meets the JASMA standard.

Unique exhaust sound designed specifically for the engine.

Remarkable Low Exhaust Pressure

φ75 pipe and straight design to deal with hard tuned engine up to 500ps！

Compatible with all year models including Final Edition.

Comfortable Driving with Less Noise

The lower exhaust resonance and interior noise under street driving were reduced.

Use with HKS Metal Catalyzer allows higher performance.

Vehicle LANCER EVOLUTION X

Model CZ4A

Engine 4B11(TURBO)

Model Year 07-16

Shape of muffler SSR (Super Turbo Muffler)

Main material S304

Diameter of tip 124

Diameter of center pipe 75 (*1)

Close Noise Level Stock L84 / R83

Close Noise Level HKS L88 / R87

Remarks

Compatible with all-year models and grades including Final Edition. Includes center pipe set.

About HKS muffler

*1: About center pipe

Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.

*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.

The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.

Caution: Hook, bracket, stay may be changed without prior notice.

★ Exhaust noise level at idle.
