INCLUDED IN KIT

Fidanza Aluminum Flywheel 161071

LUK Clutch 625 3069 00

Fits Mazda 3 MPS 07-13 & Mazda 6 MPS 06-07

Our aluminium flywheels are made from the highest quality 6061 T6 aluminium. The material is fantastic for strength, heat dissipation and of course reduction in weight.

BODY - 6061 T6 ALUMINUM Tolerances machined to +/- .001 6061 T6 has an ultimate tensile strength of at least 42,000 psi and a yield strength of at least 35,000 psi.

RING GEAR - 1050 STEEL / HEAT TREATED Heat treated for durability. The gears are heated then pressed on and secured with grade 8 button screws.

REPLACEABLE FRICTION PLATE - 1045 STEEL The friction surface we use is an incredibly strong 1045 steel. The plates are milled to meet our high specifications. With these replaceable plates there is no need to replace the entire flywheel when the clutch or flywheel is at the end of it’s life, saving time and money.

BUTTON SCREWS - GRADE 8 Increased security helping fasten the ring gear to the flywheel.

FASTENERS - MILITARY SPEC Military grade aerospace fasteners aid in pulling heat away from the clutch face. Properly spaced for form and function.

STEPPED DOWELS - STEEL Once pressure plate is installed they become locked in place. First in the industry to implement the use of stepped dowels.

Fidanza Performance lightweight aluminum flywheels deliver -

Faster throttle response and quicker acceleration

Additional horsepower to the wheels (reduced parasitic losses)

Smoother, faster shifting

Easier braking, better slowing (due to reduced rotational mass)

Reduced clutch wear and improved efficiency (from better heat dissipation)

Cost savings and longevity (replaceable friction plate = infinitely re-buildable design)

Potential for increased fuel economy (if you can keep your foot off the gas)

Quality and reliability (Made in the USA from top grade materials)

Fidanza Performance lightweight aluminum flywheels are designed, engineered and manufactured right here in the USA. Our team doesn’t just take a stock flywheel and copy it out of aluminum like some others do. We actually analyze the originals and engineer improvements where needed; whether it be in overall balance, critical clearances or improved design, our flywheels are built for performance. Machined from the highest quality 6061 T6 or 2024 T3 aluminum, each flywheel is manufactured to deliver optimum tensile strength, heat dissipation and weight reduction, without going too light and causing poor idle and driving issues like some of the ultra-lightweight competitors. We aren’t always the lightest, but we are the best!

All our aluminum flywheels are CAD designed/engineered and precision CNC machined from top quality billet aluminum forgings to strict tolerances for optimum performance and reliability. All flywheels are balanced and thoroughly inspected for quality and fitment.

VIP Motorsport is an official Dealer of Fidanza in the UK.

LUK Clutch Kit for Mazda 3 MPS 07-13 / Mazda 6 MPS 06-07

Part Number: 625 3069 00

Includes Pressure Plate, Centre Plate & Release bearing.

Works with Standard Dual Mass Flywheel & Fidanza 161071 Aluminum Flywheel.
