Xtreme Stage 1 Heavy Duty Clutch Kit 410ft/lbs for Subaru Impreza WRX/STI 1992-2007 5-Speed GC8 GF8 GG GD KSU23006-1A

Confirmed Applications

Subaru Forester 1998.06-2001.04 2.0 S Turbo AWD (SF5) EJ205 1994 Petrol 125 kW 170 BHP (1998.06 - 2001.04) Suits 5 Speed Gearbox

Subaru Forester 2001.04-2002.09 2.0 S Turbo AWD (SF5) EJ205 1994 Petrol 130 kW 177 BHP (2001.04 - 2002.09) Suits 5 Speed Gearbox

Subaru Forester 2002.02-2005.05 2.0 S Turbo AWD (SG5) EJ205 1994 Petrol 130 kW 177 BHP (2002.02 - 2005.05) Suits 5 Speed Gearbox

Subaru Forester 2003.12-2005.05 2.5 AWD (SG9) EJ25 2457 Petrol 155 kW 211 BHP (2003.12 - 2005.05) Suits 5 Speed Gearbox

Subaru Forester 2005.05-2005.09 2.5 Prodrive Performance Pack AWD EJ255 2457 Petrol 188 kW 256 BHP (2005.05 - 2005.09) Suits 5 Speed Gearbox

Subaru Impreza 1994.03-2000.12 2.0 Turbo GT AWD (GC8) EJ20 (Turbo) 1994 Petrol 155 kW 211 BHP (1994.03 - 2000.12) Suits 5 Speed Gearbox

Subaru Impreza 1994.03-2000.12 2.0 i Turbo AWD (GF8) EJ20 (Turbo) 1994 Petrol 155 kW 211 BHP (1994.03 - 2000.12) Suits 5 Speed Gearbox

Subaru Impreza 1996.12-2000.12 2.0 Turbo AWD (GC8) EJ20G 1994 Petrol 155 kW 211 BHP (1996.12 - 2000.12) Suits 5 Speed Gearbox

Subaru Impreza 1998.06-2000.12 2.0 Turbo GT AWD (GC8)

EJ205 1994 Petrol 160 kW 218 BHP (1998.06 - 2000.12) Suits 5 Speed Gearbox

Subaru Impreza 1998.06-2000.12 2.0 Turbo GT AWD (GF8) EJ205 1994 Petrol 160 kW 218 BHP (1998.06 - 2000.12) Suits 5 Speed Gearbox

Subaru Impreza 1998.09-2000.09 2.0 AWD (GC8) EJ205P 1994 Petrol 206 kW 280 BHP (1998.09 - 2000.09) Suits 5 Speed Gearbox

Subaru Impreza 2000.12-2005.12 2.0 Turbo AWD (GGA) EJ205 1994 Petrol 160 kW 218 BHP (2000.12 - 2005.12) Suits 5 Speed Gearbox

Subaru Impreza 2000.12-2005.12 2.0 WRX Turbo AWD (GDA) 5 speed EJ205 1994 Petrol 160 kW 218 BHP (2000.12 - 2005.12) Suits 5 Speed Gearbox

Subaru Impreza 2001.09-2005.12 2.0 WRX AWD (GGA) EJ205 1994 Petrol 169 kW 230 BHP (2001.09 - 2005.12) Suits 5 Speed Gearbox

Subaru Impreza 2001.11-2005.07 2.0 WRX STi AWD (GDB) EJ207 1994 Petrol 195 kW 265 BHP (2001.11 - 2005.07) Suits 5 Speed Gearbox

Subaru Impreza 2002.12-2006.09 2.0 WRX Turbo AWD (GGA) EJ205 1994 Petrol 165 kW 225 BHP (2002.12 - 2006.09) Suits 5 Speed Gearbox

Subaru Impreza 2004.02-2005.07 2.0 WRX STi AWD EJ207 1994 Petrol 235 kW 320 BHP (2004.02 - 2005.07) Suits 5 Speed Gearbox

Subaru Legacy 1992.05-1994.07 2000 Turbo 4WD (BC5) EJ20-GN 1994 Petrol 147 kW 200 BHP (1992.05 - 1994.07) Suits 5 Speed Gearbox

Subaru Legacy 1992.05-1994.07 2000 Turbo Super 4WD (BF5)

EJ20-GN 1994 Petrol 147 kW 200 BHP (1992.05 - 1994.07) Suits 5 Speed Gearbox

Subaru Legacy 2002.02-2003.06 2.0 AWD (BE5) EJ206 1994 Petrol 190 kW 258 BHP (2002.02 - 2003.06) Suits 5 Speed Gearbox

Subaru Legacy 2002.06-2003.08 2.0 AWD (BE5) EJ208 1994 Petrol 206 kW 280 BHP (2002.06 - 2003.08) Suits 5 Speed Gearbox

Specifications

Torque (Nm) Inc FOS 560

Torque (Ftlbs) Inc FOS 410

Flywheel Step FLAT

Clutch Disc Diameter (mm) 230

Clutch Disc Spline Count 24

Clutch Disc Spline Diameter (mm) 25.2

Recommended for Street Performance

Disc Type Sprung

Friction Material Organic

Clamping Force % Increase 40%

Spigot Bush / Bearing Included Yes

Aligning Tool Included Yes

Spline Grease Included Yes

Stage Stage 1

Weight [KG]: 8

Xtreme Performance - sprung organic kit /-1A

Recommended for: Street use in vehicles with minor engine modifications.

Sprung organic clutch kits offer exceptional driveability for vehicles used daily but also have performance modifications. The sprung organic disc offers improved dampening which reduces the shock loading on the transmission.

Specifications:

Torque capacity 560Nm

Clamp load 1150kg 40% Increased over standard

Organic Friction Discs

Heavy Duty Pressure Plate

Kit contains everything you need for a successful installation + accessories

Xtreme Performance

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

What's in the Box?

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

VIP Motorsport is a UK Dealer of Xtreme Clutch. GENERIC PHOTO USED - MAY NOT BE ACCURATE TO KIT RECEIVED. Contact us for a lead time.
