PERRIN PERFORMANCE HEAT SHIELD

Don't leave your turbo uncovered! Protect your intercooler from radiant heat from your turbo with the PERRIN Turbo Heat Shield!

DESIGN

The PERRIN Turbo Heat Shield is CNC formed from 304 stainless steel. The backside of the shield is cut to fit all aftermarket downpipes. It is also adjustable front to back allowing the tuner to cover as much of the turbo as possible from application to application. High quality stainless steel hardware included.

MORE COVERAGE

Our shield covers more of the turbo charger, leaving less of the exhaust housing exposed. It covers the top of the downpipe, the sides of the turbo and is formed to fit around the wastegate arm. All to help keep heat under the shield where it belongs!

ADJUSTABLE

The PERRIN Turbo Heat Shield is adjustable to allow the shield to be pulled over the turbo as much as possible.

NO RATTLES

The PERRIN Turbo Heat Shield uses spot welds, instead of rivets. When spot welds are done correctly, they will hold just as well as any bolts or rivet and will not loosen over time.

QUALITY CONTROL

The PERRIN Turbo Heat Shield uses only high quality spot welds that pass the "Nugget Test". During a production run, we actually ripped apart a test joint. The sheet metal should fail before the weld, leaving a small "nugget" of metal behind, verifying the spot weld penetrated all layers of metal.

WHY DO I NEED ONE?

It is perfect for those not wanting to cut the OEM turbo heat shield when installing our PERRIN downpipe. The PERRIN Turbo Heat Shield covers more of the turbo than competitors' shields.

FINISH

The PERRIN Tubro Heat Shield comes with a brushed stainless finish.

IN THE BOX

(1) PERRIN Heat Shield

(3) M6 Fender Washers

(3) M6 Button head socket cap screws

(1) M4 Short arm hex key

Warranty, instructions, stickers

COMPATIBILITY

Right Hand Drive cars - No, hits on break master cylinder booster

Aftermarket Turbos - Yes, stock location replacement

If you are upgrading to our heat shield on a vehicle that is missing the original shield or is missing mounting brackets, we have the OEM parts you will need listed below.

Upper Downpipe/Turbo Shield Bracket - 44021AA014

Uppipe Support Bracket - 14427AA022

05-09 LEGACY GT

05-09 OUTBACK XT

04-13 FORESTER XT

02-14 WRX

04-20 STI

VIP Motorsport is an official UK & European stockist of Perrin Performance products. Our stock is directly linked with Perrin Performance USA, if the item is out of stock with us it could take roughly 2 working weeks to be received.
